.螺牙规格:M、PG、G、NPT，符合欧盟规范。
.产品材质:A.C.E.部分以UL认可之尼龙 PA66 制成，B、D部分采用NBR丁腈橡胶制成。
.颜色种类:黑色(B) RAL9005,灰色(G) RAL7035,其它颜色请咨询
.防护等级：IP68
.工作温度:-40℃至+100℃或瞬间可耐热至 120℃。
.产品特性:特殊夹紧爪与夹紧圈之设计，夹紧电缆范围大，抗拉力特强，可防水、防尘、抗盐、耐弱酸、酒精、油、油脂及一般溶剂。
M制尼龙电缆接头
订货号 Part NO. | 规格 | 电缆范围 | 螺纹外径 | 螺纹长度 | 本体高度 | 扳手径 | 包 装 |
黑色/Black | 灰色/Grey | Thread M | Range φ(mm) | AG(mm) | GL(mm) | H(mm) | Spanner(mm) | pcs |
HNM805B | HNM805G | M8x1.25 | 2.5 ~ 4.5 | 8.0 | 7.5 | 20 | 13/12 | 100 |
HNM1007B | HNM1007G | M10x1 | 3.0 ~ 6.5 | 10.0 | 8.0 | 22 | 15 | 100 |
HNM1205B | HNM1205G | M12x1.5 | 2.0 ~ 5.0 | 12.0 | 8.0 | 22 | 16 | 100 |
HNM1207B | HNM1207G | 3.0 ~ 6.5 | 12.0 | 8.0 | 22 | 16 | 100 |
HNM1406B | HNM1406G | M14x1.5 | 2.0 ~ 6.0 | 14.0 | 8.0 | 26 | 19 | 100 |
HNM1408B | HNM1408G | 4.0 ~ 8.0 | 14.0 | 8.0 | 26 | 19 | 100 |
HNM1607B | HNM1607G | M16x1.5 | 3.0 ~ 7.0 | 16.0 | 8.0 | 27 | 22 | 100 |
HNM1608B | HNM1608G | 4.0 ~ 8.0 | 16.0 | 8.0 | 26 | 19 | 100 |
HNM1610B | HNM1610G | 5.0 ~ 10.0 | 16.0 | 8.0 | 27 | 22 | 100 |
HNM1807B | HNM1807G | M18x1.5 | 3.0 ~ 7.0 | 18.0 | 8.0 | 27 | 22 | 100 |
HNM1810B | HNM1810G | 5.0 ~ 10.0 | 18.0 | 8.0 | 27 | 22 | 100 |
HNM2009B | HNM2009G | M20x1.5 | 5.0 ~ 9.0 | 20.0 | 9.0 | 28 | 24 | 100 |
HNM2012B | HNM2012G | 6.0 ~ 12.0 | 20.0 | 9.0 | 28 | 24 | 100 |
HNM2014B | HNM2014G | 10.0 ~ 14.0 | 20.0 | 10.0 | 30 | 27 | 100 |
HNM2212B | HNM2212G | M22x1.5 | 6.0 ~ 12.0 | 22.0 | 10.0 | 30 | 27 | 100 |
HNM2214B | HNM2214G | 10.0 ~ 14.0 | 22.0 | 10.0 | 30 | 27 | 100 |
HNM2412B | HNM2412G | M24x1.5 | 10.0 ~ 12.0 | 24.0 | 10.0 | 30 | 27 | 100 |
HNM2415B | HNM2415G | 12.0 ~ 15.0 | 24.0 | 10.0 | 30 | 27 | 100 |
HNM2516B | HNM2516G | M25x1.5 | 9.0 ~ 16.0 | 25.0 | 10.0 | 35 | 33 | 100 |
HNM2518B | HNM2518G | 13.0 ~ 18.0 | 25.0 | 10.0 | 35 | 33 | 100 |
HNM2716B | HNM2716G | M27x1.5 | 9.0 ~ 16.0 | 27.0 | 10.0 | 35 | 33 | 100 |
HNM2718B | HNM2718G | 13.0 ~ 18.0 | 27.0 | 10.0 | 35 | 33 | 100 |
HNM3015B | HNM3015G | M30x1.5 | 7.0 ~ 15.0 | 30.0 | 11.0 | 34 | 35/36 | 50 |
HNM3021B | HNM3021G | 16.0 ~ 21.0 | 30.0 | 11.0 | 34 | 35/36 | 50 |
HNM3220B | HNM3220G | M32x1.5 | 13.0 ~ 20.0 | 32.0 | 12.0 | 40 | 41/42 | 50 |
HNM3221B | HNM3221G | 16.0 ~ 21.0 | 32.0 | 11.0 | 34 | 36/37 | 50 |
HNM3225B | HNM3225G | 18.0 ~ 25.0 | 32.0 | 12.0 | 40 | 41/42 | 50 |
HNM3620B | HNM3620G | M36x1.5 | 13.0 ~ 20.0 | 36.0 | 12.0 | 40 | 41/42 | 50 |
HNM3625B | HNM3625G | 18.0 ~ 25.0 | 36.0 | 12.0 | 40 | 41/42 | 50 |
HNM4026B | HNM4026G | M40x1.5 | 20.0 ~ 26.0 | 40.0 | 14.0 | 48 | 52/53 | 20 |
HNM4032B | HNM4032G | 22.0 ~ 32.0 | 40.0 | 14.0 | 48 | 52/53 | 20 |
HNM5031B | HNM5031G | M50x1.5 | 25.0 ~ 31.0 | 50.0 | 14.0 | 49 | 60/61 | 20 |
HNM5038B | HNM5038G | 32.0 ~ 38.0 | 50.0 | 14.0 | 49 | 60/61 | 20 |
HNM6335B | HNM6335G | M63x1.5 | 29.0 ~ 35.0 | 63.0 | 14.0 | 50 | 67 | 20 |
HNM6344B | HNM6344G | 37.0 ~ 44.0 | 63.0 | 14.0 | 50 | 67 | 20 |
HNM7555B | HNM7555G | M75x2.0 | 48.0 ~ 55.0 | 75.0 | 25.0 | 63 | 82 | 4 |
HNM7560B | HNM7560G | 53.0 ~ 60.0 | 75.0 | 25.0 | 63 | 82 | 4 |
HNM8070B | HNM8070G | M80x2.0 | 65.0 ~ 70.0 | 80.0 | 28.0 | 74 | 90/98 | 4 |
HNM8870B | HNM8870G | M88x2.0 | 65.0 ~ 70.0 | 88.0 | 28.0 | 74 | 98 | 4 |
HNM10090B | HNM10090G | M100x2.0 | 85.0 ~ 90.0 | 100.0 | 28.0 | 70 | 110/117 | 4 |
HNM11490B | HNM11490G | M114x2.0 | 85.0 ~ 90.0 | 114.0 | 28.0 | 72 | 116/122 | 4 |
