型号

产品规格

螺纹规格

螺纹规格

电缆范围

主体外径

接合长度

螺纹长度

Part NO.

Item

Thread D

Thread d1

Range φ(mm)

D1(mm)

H(mm)

H1(mm)

HNTJ8

TJ-8

M16x1

M14x1

5.0 ~ 7.0

20.0

32.0

9.0

HNTJ13

TJ-13

M20x1

M18x1

6.0 ~ 12.0

24.0

35.0

10.0

HNTJ16

TJ-16

M27x1.5

M22x1.5

11.0 ~ 15.0

31.5

40.0

12.0

HNTJ19

TJ-19

M30x1.5

M27x1.5

14.0 ~ 18.0

34.5

42.0

12.0

HNTJ24

TJ-24

M35x1.5

M30x1.5

17.0 ~ 23.0

39.6

44.0

12.0

HNTJ28

TJ-28

M42x2

M36x1.5

22.0 ~ 27.0

46.5

46.0

15.0

HNTJ34

TJ-34

M47x2

M42x2

26.0 ~ 33.0

54.0

49.0

15.0

HNTJ42

TJ-42

M55x2

M52x2

32.0 ~ 41.0

62.0

54.0

15.0

HNTJ50

TJ-50

M62x2

M58x2

40.0 ~ 49.0

68.5

56.0

15.0

HNTJ58

TJ-58

M71x2

M68x2

48.0 ~ 57.0

77.5

56.0

20.0
