.螺牙规格:M、PG、G、NPT，符合欧盟规范 .产品材质:尼龙66、丁腈橡胶
.防护等级：IP54 .温度范围: -40℃至+115℃~150℃
.产品特性: 内锁扣和本体特殊设计，装卸只需要插拔，无需工具
注：特殊规格需要请联系工厂PG制螺纹 PG Thread
订货号 Part NO. | 适配软管 | 螺纹规格 | AG外径 | AG孔径 | 螺纹长度 | 主体高度 | 包 装 |
黑色/Black | 灰色/Grey | AD(mm) | Thread | AG (mm) | (mm) | GL(mm) | H (mm) | pcs |
HN10.0-PG7B | HN10.0-PG7G | 10.0 | PG7 | 12.5 | 6.5 | 10.0 | 23.0 | 100 |
HN11.6-PG7B | HN11.6-PG7G | 11.6 | PG7 | 12.5 | 8.0 | 10.0 | 23.0 | 100 |
HN13.0-PG9B | HN13.0-PG9G | 13.0 | PG9 | 15.2 | 10.0 | 10.0 | 25.0 | 100 |
HN15.8-PG11B | HN15.8-PG11G | 15.8 | PG11 | 18.6 | 12.0 | 10.0 | 27.0 | 100 |
HN15.8-PG13.5B | HN15.8-PG13.5G | PG13.5 | 20.4 | 12.5 | 10.0 | 28.0 | 100 |
HN18.5-PG13.5B | HN18.5-PG13.5G | 18.5 | PG13.5 | 20.4 | 14.3 | 12.0 | 28.0 | 100 |
HN21.2-PG16B | HN21.2-PG16G | 21.2 | PG16 | 22.5 | 17.0 | 13.0 | 32.0 | 50 |
HN28.5-PG21B | HN28.5-PG21G | 28.5 | PG21 | 28.3 | 23.0 | 14.0 | 34.0 | 50 |
HN34.5-PG29B | HN34.5-PG29G | 34.5 | PG29 | 37.0 | 29.0 | 14.0 | 36.0 | 20 |
HN42.5-PG36B | HN42.5-PG36G | 42.5 | PG36 | 47.0 | 36.0 | 14.0 | 38.5 | 20 |
HN54.5-PG48B | HN54.5-PG48G | 54.5 | PG48 | 59.3 | 48.0 | 15.0 | 40.0 | 10 |
