.螺牙规格:PG、M、G、NPT，符合欧盟规范 .产品材质:尼龙66、丁腈橡胶
.防护等级：IP66 .温度范围: -40℃至+115℃
.产品特性: 夹紧圈与密封件特殊之设计，配合迫紧头装配省时便利，夹紧软管范围大，抗拉力特强，可防水、防尘、防盐，耐酸碱、酒精、油及一般溶剂
注：特殊规格需要请联系工厂
公制螺纹 Metric Thread
订货号 Part NO. | 适配软管 | 螺纹规格 | AG外径 | AG孔径 | 螺纹长度 | 主体高度 | 包 装 |
黑色/Black | 灰色/Grey | AD(mm) | Thread | AG (mm) | (mm) | GL(mm) | H (mm) | pcs |
HNF10.0-M12B | HNF10.0-M12G | 10.0 | M12x1.5 | 12.0 | 7.0 | 9.0 | 19.0 | 50 |
HNF10.0-M16B | HNF10.0-M16G | M16x1.5 | 16.0 | 7.0 | 9.0 | 19.0 | 50 |
HNF13.0-M16B | HNF13.0-M16G | 13.0 | M16x1.5 | 16.0 | 10.0 | 10.0 | 20.0 | 50 |
HNF15.8-M16B | HNF15.8-M16G | 15.8 | M16x1.5 | 16.0 | 12.0 | 10.0 | 20.0 | 50 |
HNF15.8-M20B | HNF15.8-M20G | M20x1.5 | 20.0 | 12.0 | 10.0 | 20.0 | 50 |
HNF15.8-M22B | HNF15.8-M22G | M22x1.5 | 22.0 | 12.0 | 10.0 | 20.0 | 50 |
HNF15.8-M25B | HNF15.8-M25G | M25x1.5 | 25.0 | 12.0 | 12.0 | 22.0 | 50 |
HNF18.5-M16B | HNF18.5-M16G | 18.5 | M16x1.5 | 16.0 | 14.5 | 10.0 | 20.0 | 50 |
HNF18.5-M20B | HNF18.5-M20G | M20x1.5 | 20.0 | 14.5 | 10.0 | 20.0 | 50 |
HNF18.5-M22B | HNF18.5-M22G | M22x1.5 | 22.0 | 14.5 | 10.0 | 20.0 | 50 |
HNF18.5-M25B | HNF18.5-M25G | M25x1.5 | 25.0 | 14.5 | 12.0 | 22.0 | 50 |
HNF21.2-M20B | HNF21.2-M20G | 21.2 | M20x1.5 | 20.0 | 17.0 | 10.0 | 20.0 | 50 |
HNF21.2-M25B | HNF21.2-M25G | M25x1.5 | 25.0 | 17.0 | 10.0 | 25.0 | 50 |
HNF25.0-M20B | HNF25.0-M20G | 25.0 | M20x1.5 | 20.0 | 20.0 | 10.0 | 20.0 | 50 |
HNF25.0-M25B | HNF25.0-M25G | M25x1.5 | 25.0 | 20.0 | 10.0 | 25.0 | 50 |
HNF28.5-M25B | HNF28.5-M25G | 28.5 | M25x1.5 | 25.0 | 23.0 | 10.0 | 25.0 | 50 |
HNF34.5-M32B | HNF34.5-M32G | 34.5 | M32x1.5 | 32.0 | 29.0 | 10.0 | 30.0 | 20 |
HNF42.5-M40B | HNF42.5-M40G | 42.5 | M40x1.5 | 40.0 | 36.0 | 15.0 | 40.0 | 10 |
HNF42.5-M50B | HNF42.5-M50G | M50x1.5 | 48.0 | 36.0 | 15.0 | 40.0 | 10 |
HNF54.5-M50B | HNF54.5-M50G | 54.5 | M50x1.5 | 50.0 | 48.0 | 22.0 | 46.0 | 10 |
HNF54.5-M63B | HNF54.5-M63G | M63x1.5 | 63.0 | 48.0 | 25.0 | 49.0 | 10 |
