.产品材质:黄铜镀镍 .散热透气:2400ml/s/m²@
.防护等级：IP68 .温度范围: -40℃至+100℃
.应用领域:LED灯具，户外电源，传感器，安防监控，光伏汇流箱，光伏逆变器，汽车变速箱等领域
注：特殊规格需要请联系工厂
订货号 | 标准螺牙 | 适用电缆 | 螺纹外径 | 螺纹长度 | 本体高度 | 扳手径 | 包 装 |
Part NO. | Thread M | Range φ(mm) | AG(mm) | GL(mm) | H(mm) | Spanner(mm) | pcs |
HNNBPM1207 | M12x1.5 | 3.0 ~ 6.5 | 12.0 | 6.5 | 27 | 16 | 50 |
HNNBPM1208 | 4.0 ~ 8.0 | 12.0 | 8.0 | 27 | 16/14 | 50 |
HNNBPM1606 | M16x1.5 | 3.0 ~ 6.0 | 16.0 | 8.0 | 27 | 18 | 50 |
HNNBPM1608 | 4.0 ~ 8.0 | 16.0 | 8.0 | 27 | 18 | 50 |
HNNBPM1610 | 5.0 ~ 10.0 | 16.0 | 8.0 | 27 | 20/18 | 50 |
HNNBPM1810 | M18x1.5 | 5.0 ~ 10.0 | 18.0 | 8.0 | 29 | 20 | 50 |
HNNBPM2010 | M20x1.5 | 5.0 ~ 10.0 | 20.0 | 8.0 | 32 | 22 | 50 |
HNNBPM2012 | 6.0 ~ 12.0 | 20.0 | 8.0 | 32 | 22 | 50 |
HNNBPM2014 | 10.0 ~ 14.0 | 20.0 | 8.0 | 32 | 24/22 | 50 |
HNNBPM2512 | M25x1.5 | 8.0 ~ 12.0 | 25.0 | 9.0 | 35 | 24/27 | 25 |
HNNBPM2514 | 10.0 ~ 14.0 | 25.0 | 9.0 | 35 | 24/27 | 25 |
HNNBPM2516 | 12.0 ~ 16.0 | 25.0 | 9.0 | 35 | 27 | 25 |
HNNBPM2518 | 13.0 ~ 18.0 | 25.0 | 9.0 | 35 | 30/27 | 25 |
HNNBPM3218 | M32x1.5 | 13.0 ~ 18.0 | 32.0 | 10.0 | 54 | 35 | 25 |
HNNBPM3222 | 15.0 ~ 22.0 | 32.0 | 10.0 | 54 | 35 | 10 |
HNNBPM3225 | 18.0 ~ 25.0 | 32.0 | 10.0 | 54 | 40/35 | 10 |
HNNBPM4025 | M40x1.5 | 18.0 ~ 25.0 | 40.0 | 11.0 | 46 | 40/45 | 10 |
HNNBPM4030 | 22.0 ~ 30.0 | 40.0 | 11.0 | 50 | 45 | 10 |
HNNBPM4033 | 25.0 ~ 33.0 | 40.0 | 11.0 | 52 | 50/45 | 10 |
HNNBPM5038 | M50x1.5 | 32.0 ~ 38.0 | 50.0 | 13.0 | 55 | 57/55 | 10 |
HNNBPM6344 | M63x1.5 | 37.0 ~ 44.0 | 63.0 | 14.0 | 55 | 64/68 | 5 |
HNNBPM6352 | 42.0 ~ 52.0 | 63.0 | 14.0 | 55 | 78/68 | 5 |
